PEX Series (Economy and compact size)




High Functions and Water-proof
Detecting distance : Through-beam type 10m,
Retro-reflection type 2.6m & Diffuse-reflection type 0.5m
*Protective structure is IP67
*Connector type is lined-up
*Stable lamp provides
*Both PNP and NPN output are lined-up
Through-beam type
Standard (NPN output) : PEX-105C
With connector (NPN output) :
PEX-105C-J
Standard (PNP output) :
PEX-105A
With connector (PNP output) :PEX-105A-J
Retro-reflective type

Standard (NPN output) : PEX-263C
With connector (NPN output) :
PEX-263C-J
Standard (PNP output) :
PEX-263A
With connector (PNP output) :PEX-263A-J
Diffuse-reflection type
Basic:
Standard (NPN output) : PEX-501C
With connector (NPN output) :
PEX-501C-J
Standard (PNP output) :
PEX-501A
With connector (PNP output) :PEX-501A-J
Short distance(NPN output only):
Standard (10-90mm) : PEX-102C
With connector (10-90mm)NPN output) :
PEX-102C-J
Standard (1-70mm) :
PEX-002C
With connector (1-70mm) :PEX-002C-J
Note)
Sales: ASIA market only


PLX Series (Equivalent model of PL8 series!)


Through-beam type 10m, Retro-reflective type (with polarized filter) 4m & Diffuse reflection type 70cm
*Free power source, 24 to 240VAC/12 to 110VDC
*Protective structure IP66

Through-beam type
30m or less : PLX-305W
10m or less : PLX-105W
Retro-reflection type
PLX-403W
Diffuse-reflection type
Dark-ON : PLX-701L
Light-ON : PLX-701R

F- series(FC/FB/FG)(U-shape type)

U-shape photoelectric sensor
Suitable for position detection
It operates when the detectable objects pass and interrupt the beam through the opening of this U-shape sensor
Applications :
*Detect address striker of stacker crane
*Stop at specific position of the stacker crane, AGV, the elevator and the stocker


For the detail specifications, please click here!···(CATALOGUE)
